Measurement range
Measurement pressure:(0~60)MPa
Measurement accuracy: ±0.02% FS
Output range
Output pressure: (1~60)MPa
Measurement accuracy: ±0.02% FS, ±0.05% FS
Working medium: Mineral oil
External standard device: Range is not greater than the built-in pressure standard module, the external standard device range(0 ~ 6MPa, 0 ~ 25MPa), ±0.02%FS
External pressure source: 0.7MPa<Pressure source range <1MPa; Dimensions: (500 × 490 × 580) mm; Weight: 50kg
Control stability: ≤0.003% full scale
Pressure output stabilization time: Continuous output of more than 5 mins
Minimum controllable fineness adjustment: 0.01MPa
Screen size: 7-inch touchscreen display
Pressure input connector: 6mm standard test hose
Pressure output connector: Four M20 × 1.5 or NPT/BSP Female optional
Working environment: Ambient temperature (0~50)°C; Relative humidity ≤90%
Power supply: 220VAC
Dimensions: (610 × 360 × 370) mm
Weight: 34kg
