Max drilling diameter and tapping diameter: Φ25/M16
Max travel of spindle: 110
Max distance from spindle to generating line of column: 240
Max distance between spindle end to the worktable surface: 630
Max distance from spindle end to the surface of base worktable: 1100
Max travel of spindle box: 250
Max travel of worktable and bracket (Mannual/Mechanical): 450
Spindle taper bore: 3
Spindle speed steps: 6
Spindle speed range: 125-2825
Dimension of worktable: 350x400
Effective working area of worktable: 310x320
Diameter of column: Φ95
Power of motor: 0.75
Machine dimension: 700x500x1900
Packing dimension: 830x530x1950
Net weight/Gross weight: 300/350
Accessories: Shalf sleeve for taper shank tool, Key type drill chuck, Connecting bar for drill chuck, Wedge for taper shank tool, Double open end spanner.
