Max drilling diameter and tapping diameter: Φ30/M20
Max travel of spindle: 135
Max distance from spindle to generating line of column: 260
Max distance from spindle end to the surface of base worktable: 700
Max travel of spindle box: 520
Spindle taper bore: 3
Spindle speed steps: 12
Spindle speed range: 125~3030
Effective working area of worktable: 335x340
Diameter of column: Φ110
Power of motor: 0.85/1.1
Machine dimension: 740x420x1610
Packing dimension: 820x620x2270
Net weight/Gross weight: 315/360
Accessories: Shalf sleeve for taper shank tool, Key type drill chuck, Connecting bar for drill chuck, Wedge for taper shank tool, Double open end spanner.
