Max.drilling diameter(on Medium-carbon steel)(mm): Ø80
Max.drilling diameter(on cast iron)(mm): Ø105
Max.tapping diameter(on Medium-carbon steel): M52
Max.tpping diameter(on cast iron): M60
Max.distance from spindle to generating line of colum(mm): 450-2550
Distance of horizontal movement for spindle box(manual)(mm): 2100
Max.distance between spindle endto the worktable surface of the base(mm): 400-1620
Max.travel of the spindle(mm): 400
Spindle taper bore: MT.6
Spindle speed step: Stepless
Spindle speed range(r/min): 30-220 / 192-1400
Spindle feed steps: 8
Spindle feed range(mm/r): 0.06, 0.09, 0.15, 0.23, 0.36, 0.60, 0.90, 1.38
Speed of rocker arm up and down movement(m/min): 1
Rotation angle of rocker arm.(degree): ±180
Distance of spindle movement for calibrated dial each revolution(mm): 151
Power of main motor(tranducer motor)(KW): 7.5
Power of motor for rocker arm up and down movement(KW): 2.2
Power of oil pump motor for spindle box,column and rocker arm clamping(KW): 1.1
Weight of machine(kg): 7400
Machine dimension(LxWxH)(mm): 3590x1250x3530
