Nominal force (KN): 4000
Knock-out force (KN): 630
Max. working hydraulic pressure (Mpa): 25
Slide-stroke (mm): 800
Knock-out stroke (mm): 300
Max. Daylight (mm): 1300
Slide speed
Descent (mm/s): 100
Working (mm/s): 4
Return (mm/s): 60
Effective area of table
Left-right (mm): 1200
Front-back (mm): 1200
Overall Size
Left-right (mm): 3235
Front-back (mm): 2200
Height above ground (mm): 4500
Total motor power (kw): 22
Weight (kg): 22000
