Nominal Pressure (kN): 6300
Nominal Pressure Stroke (mm): 13
Stroke of Slide (mm): 280
Strokes (S.P.M): 15-20
Die Height Adjustment (mm): 120
Max. Die Set Height (mm): 550
Bottom Size of Slide (mm): 1200 x 1400
Distance Between Uprights (mm): 1800
Left and right openring in uprights (mm): 1000
Size of Table (mm): 1300 x 1700
Thickness of Table (mm): 220
Size Opening in the Table (mm): 160 x 600
Hole for inch Shank (mm): F70 x 100
Main Motor Power (KW): 75
Overall size (cm): 380x280x510
Weight (ton): 66
