Nominal Pressure (kN): 4000
Nominal Pressure Stroke (mm): 8
Stroke of Slide (mm): 180
Strokes
Variable (S.P.M): 25-40
Single (S.P.M): 30
Max. Die Set Height (mm): 585
Die Height Adjustment (mm): 120
Depth of Throat (mm): 480
Distance between Uprights (mm): 1050
Size of Table
L-R (mm): 1850
F-B (mm): 940
Thickness (mm): 200
Size of Opening in Table
Diameter (mm): F250
Bottom Size of Slide
L-R (mm): 1000
F-B (mm): 720
Hole for Punch Shank
Diamente (mm): F70
Depth (mm): 100
Single Speed Motor Power (kw): 37
Variable Motor Power (kw): 37
Overall Dimensions
F-B (mm): 3800
L-R (mm): 2200
Heigth (mm): 4300
Total Weight (kg): 43000
