Max.swing over bed: F410mm(16")
Max.swing over slide: F240mm/F150mm(gang tools)
Max.cross travel(X): 235/300mm(gang tools)
Max.length of workpiece: 500、750、1000mm
Rapid feed for Axis X: 5m/min
Rapid feed for Axis Z: 8m/min
Range of spindle speeds(Stepless): 200-2800r/min
Spindle bore: F52
Taper bore of spindle: MT No.6
3-jaw chuck of collet: F200 or 5c
Tool post: 4-way or 6-way or gang tools
Servomotor power(X/Z): 0.75/1.0kW servomotors
Size of tool shank: 20x20mm
Min.input: 0.001mm
Repeatability(X/Z): 0.0075/0.01mm
Surface roughness: ≤Ra0.8µm(Nonferrous)≤Ra1.6µm(Steel part)
Main motor power: 3.7KW(5HP)
Overall dimensions(L X W X H): (1870,2120,2370)x1200x1415mm
Net weight: 1800,2100,2300
