SMAC CK40 CNC Slant Lathe

Max.swing over bed (mm): φ750

Max.cutting dia.for disc parts (mm): φ750

Max.cutting dia. for axe parts (mm): φ350

Maximum turned length (mm): 870

Max.cross trave (X) (mm): 370

Max.omgitudina trave (Z) (mm): 1050

Rapid feed for axis X (m/min): 10

Rapid feed for axis Z (m/min): 20

Max.speed of spindle (rpm): 100-2000

Diamrter of spindle thru hoe (mm): φ105

Spinde nose: φ220

Hydrauic chuck (mm): 12"

Number of toos: 12(hydraulic)

Outside dia.Of cutting too shank (mm): 25x25

Inner dia. Of cutting too shank (mm): φ32

Taistock seeve dia. (mm): φ100

Taistock seeve trave (mm): 210

taistock center type: M.T.No.6

Min.Input (mm): 0.001

Servo motor power for x axis (NM): 15

Servo motor power for z axis (NM): 22

Slant bed integrated with stand: 30˚

Guide ways X & Z: Precision linear guides

Surfacce roughness: ≤Ra0.8mm (Nonferrous) ≤Ra1.6mm (Stee part)

Main motor power (KW): 15

Overa dimension mode (LxWxH) (cm): 337x225x196

Net weight (kg):5400

Standard Accessories: Total sealed fencing system; Lubrication system; solid hydraulic chuck; Optional manual

Optional Accessories: Hollowed hydraulic chuck; Automatic conveying system; Hydraulic tailstock
