BatteryType: LiFePO4
Rated Capacity: 16.076kWh
Usable Capacity: 15.27kWh (D0D 95%, 0.5C)
Rated Voltage: 51.2V
Operating Voltage Range: 40~58.4V
Max. Continurous Charging Current: 150A
Max.Continurous Discharging Current: 150A
Max. Pulse Dicharging Current: 300A @1s
Balancing Method: Passive Balancing
Cycle Life: ≥8000 cycles @ 25℃ with 0.5C 70%EOL
Communication: WiFi Dongle,RS485/CAN
Operating Temperature: Charging: 0℃~55℃ / Discharging: -20℃~60℃
Storage Temperature: -20℃~45℃
Operating Humidity: 5~95%
Operating Altitude: ≤3000m
Cooling Method: Natural Cooling
Ingress Protection: IP20 for indoor installation.
Parallel Connection: ≤4
Indicator: Color Bar (showing SOC and charging status)
Remote Management: Over-the-air upgrade, Realtime management via App & Web
Weight: Approx.125kg
Dimension (WxDxH): 610 x270x833mm (With wheels)
Mounting Method: Floor-Stand (with lock castors)
Loading capacity: 90 PCS per 20' GP container
