Polarity: Unidirectional
Shutdown: Shutdown
Data Rate: 10 Mb/s
Input Type: Schmitt Trigger
Output Type: CMOS
Pulse Width: 100 ns
Unit Weight: 80 mg
Isolation Type: Capacitive Coupling
Mounting Style: SMD/SMT
Development Kit: si80xxiso-kit
Forward Channels: 5 Channel
Reverse Channels: 0 Channel
Isolation Voltage: 1500 Vrms
Maximum Fall Time: 4 ns
Maximum Rise Time: 4 ns
Moisture Sensitive: Yes
Number of Channels: 5 Channel
Protocol Supported: General Purpose
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 3.15 V
Propagation Delay Time: 40 ns
Pulse Width Distortion: 30 ns
Operating Supply Current: 4.4 mA, 9.4 mA
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
