Surge test voltage: Up to 6kV (1.2/50us waveform)
Coupling mode: Wire to ground (common mode)
Coupling method: 90V gas discharge tube + 160Ω resistance/each wire, 4 wires at the same time-ground (common mode)
Surge injection interface: 4mm socket
Test product interface: 4mm socket/shortcut terminal block
Terminal layout:
- 4 wires (the first pair of wires L1-L2, the second pair of wires L3-L4)
- 2-wire (L1, L2 in parallel, L3+L4 in parallel)
Data transfer rate: 100MBit/s
Operating Voltage: Max 50V DC
Working current: Maximum 1A
Dimensions: 257mm×168mm×355mm
weight: About 10kg
Use environment: Temperature: 10℃～35℃, relative humidity: 30%～60%
