Siretta OSCAR20A/5M/SMAM/S/S/15 Passive Antenna 5G/4G/LORA/SIGFOX/BLUETOOTH/ZIGBEE DIRECTIONAL YAGI ANTENNA SMA MALE CONNECTOR 5M CABLE

Gain: 7 dB to 8 dB

VSWR: 2.0:1

Style: Directional

Width: 147 mm

Height: 35 mm

Length: 170 mm

Frequency: 850 MHz, 900 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2600 MHz

Impedance: 50 Ohms

Cable Type: 5 M RG58

Application: Cellular Applications

Unit Weight: 499 g

Cable Length: 5 m

Polarization: Vertical

Power Rating: 50 W

REACH - SVHC: Details

Mounting Style: Bracket Mount

Frequency Range: 850 MHz to 2.6 GHz

Number of Bands: 4 Band

Center Frequency: 850 MHz, 900 MHz, 1800 MHz, 1900 MHz, 2100 MH, 2500 MHz

Mechanical Style: Log Periodic

Maximum Frequency: 2.6 GHz

Minimum Frequency: 850 MHz

Termination Style: Connector

Protocol - Sub GHz: ISM

Antenna Connector Type: SMA Female

Protocol - WiFi - 802.11: WLAN

Maximum Operating Temperature: + 70 C

Minimum Operating Temperature: - 30 C

Protocol - Cellular, NBIoT, LTE: 2G/3G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, GRPS, PCS
