Color: Green
Gender: Plug (RP - Female)
Insulation: Insulated
Contact Type: Socket
Mating Gender: Receptacle
Contact Gender: Without Socket Contacts
Current Rating: 25 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 2 Row
Wire Gauge Max: 10 AWG
Wire Gauge Min: 14 AWG
Housing Material: Thermoplastic (TP)
Wire Gauge Range: 10 AWG to 14 AWG
Ingress Protection: IP67
Mating Part Number: ATP04-6P
Flammability Rating: UL 94 V-0
Number of Positions: 6 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
