Input Voltage: ±30 kVDC max
Output Current Continuous Use: 0.75 mA/ft max
Intermittent Use: 1.50 mA/ft max
Operating Env.: 32°F (0°C) to 200°F (90°C); 70% RH max, no dewing permissible
Operating Distance: 1/2” to 3” (application & voltage dependent)
Weight: 1.4 lb per foot
Dimensions: 1” W x 1.9” H x (EL + 2”) L
EL = Effective Length: 3” to 144” in 3” increments
Enclosure: Glass filled polyester (rugged, impact resistant, light grey color)
High Voltage Cable: Flexible, abrasion-resistant, silicone outer jacket rated to ±50 kV, 10-ft standard length (1/2” min bend radius)
