Silvertel Ag9705-2BR Adjustable Output PoE PD Module, 9W, 5V Output, inc. Bridge Rectifiers, IEEE802.3af compliant, Single-in-line

Width: 19 mm

Height: 14 mm

Length: 56 mm

Features: Short-circuit Protection

Compliance: 802.3af

Efficiency: 80 %

Unit Weight: 17.094 g

Output Power: 9 W

REACH - SVHC: Details

Input Voltage: 36 V to 57 V

Mounting Style: Through Hole

Load Regulation: Regulated

Number of Ports: 1 Port

Number of Outputs: 1 Output

Output Current-Channel 1: 1.8 A

Output Voltage-Channel 1: 5 V

Maximum Operating Temperature: + 70 C

Minimum Operating Temperature: - 20 C
