Core: 8051
Width: 3 mm
Height: 0.88 mm
Length: 3 mm
Unit Weight: 24.090 mg
Data RAM Size: 256 B
Data ROM Size: 128 B
Data ROM Type: Flash
ADC Resolution: 8 bit
Data Bus Width: 8 bit
Interface Type: I2C, SMBus, UART
Mounting Style: SMD/SMT
Number of I/Os: 8 I/O
Processor Series: C8051
Program Memory Size: 8 kB
Program Memory Type: Flash
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 2.7 V
Number of ADC Channels: 8 Channel
Maximum Clock Frequency: 25 MHz
Number of Timers/Counters: 3 Timer
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
