Core: ARM Cortex M4
Range: 50 m
Width: 9.15 mm
Height: 1.9 mm
Length: 15.73 mm
Antenna: Chip
Features: Integrated DC-DC Converter, Onboard Bluetooth Stack
Protocol: BLE, Bluetooth 4.2
Data Rate: 1 Mb/s
Frequency: 2.44 GHz
Shielding: Shielded
Dimensions: 15.73 mm x 9.15 mm x 1.9 mm
Memory Size: 256 kB
Sensitivity: - 92 dBm
Output Power: 3 dBm
Interface Type: GPIO, I2C, SPI, UART
Mounting Style: SMD/SMT
Frequency Range: 2.4 GHz to 2.4835 GHz
Moisture Sensitive: Yes
Modulation Technique: GFSK
Receiver Sensitivity: - 92 dBm
Supply Voltage - Max: 3.3 V
Supply Voltage - Min: 3.3 V
Antenna Connector Type: Integrated
Operating Supply Voltage: 3.3 V
Supply Current Receiving: 8.7 mA
Supply Current Transmitting: 8.2 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
