Core: ARM Cortex M4
Range: 200 m
Width: 12.9 mm
Height: 2.2 mm
Length: 15 mm
Antenna: Dipole
Features: Integrated DC-DC Converter, Onboard Bluetooth Stack
Protocol: BLE, Bluetooth 4.2
Data Rate: 1 Mb/s
Frequency: 2.44 GHz
Dimensions: 15 mm x 12.9 mm x 2.2 mm
Memory Size: 256 kB
Sensitivity: - 92 dBm
Unit Weight: 7.396 g
Output Power: 8 dBm
Interface Type: GPIO, I2C, SPI, UART
Mounting Style: SMD/SMT
Frequency Range: 2.4 GHz to 2.4835 GHz
Moisture Sensitive: Yes
Modulation Technique: GFSK
Receiver Sensitivity: - 92 dBm
Supply Voltage - Max: 3.8 V
Supply Voltage - Min: 1.85 V
Antenna Connector Type: U.FL
Operating Supply Voltage: 1.85 V to 3.8 V
Supply Current Receiving: 8.7 mA
Supply Current Transmitting: 8.2 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
