ShutterStar X-3500 X-ray Inspection

Dimension：940*1504*1630 mm
Weight：926 KG
Power Supply：Single phase AC 110~230V/50~60HZ
X-Ray Tube Type: Closed tube
Focal Spot：5 um
Field of view：0 ~ 70℃ tilt、360℃ rotate
X-ray Output Voltage：100 KV
Magnification：125(Geometric )/1200(System)
Camera Spec.：Image Intensifier+Digital CCD 25 frames/m
CCD Pixel： 1.3 million
Image Resolution：110 LP/CM
Image area：460*370 mm
Safty：Leakage＜＝0.5 μsv/h
Display：20" LCD monitor
Testable Weight：sample ＜5 ㎏
Work Table：X / Y / Z / Q Axis
Manual Operation：by keyboard/mouse/navigation positioning
CPU：Intel Pentium
Memory：2GB
Computer System：WINDOWS XP Professional
Input：Keyboard
Report Output：Manual/auto save tested doc
video Function：Standard
Navigation：Automatic scanning navigation
3D View：Imitation
Void, BGA, Distance Inspection：Auto-inspect function settable
BGA Auto Inspection：set the counting of BGA inspection,measurement and bubble
Inspection Area：X / Y plane direction
Special Isolation：Non
Temperature、Humidity：0-40℃ 10-90%
