Input Power: DC24V (AC adaptor AC100~240V available)
Capacity: 10 VA
Output voltage: ±7,500 V0-p
Ion balance: Below ±10 V(Distance at 300mm)
Air Volume: 1.4 to 3.2 m3 / min
Air Speed:
1.8 to 3.8 m/sec(with Straight Louver at 300mm center)
0.4 to 0.6 m/sec(with Wide angle Louver at 300mm center)
Ozone Density: Below 0.004 ppm(Distance at 150mm)
Available Environment: Indoor use, 0 to 40℃, 15~85%RH (without condensation)
Filter: Pre-filter level
Signal Output:
Normal: ON
H.V Output abnormal or Fan abnormal (Red LED): OFF
MOS FET Relay, Normally Close contact output
Maximum current: 200 mA
Apply voltage: 30 VDC or less
Main unit Dimensions: 150×182×66 mm (W×H×D) not including Fixing Bracket and projecting portion
Weight: Appox 1.0 kg(with Bracket)
Noise Level: 59dB (A) (at 1m distance)
Accessories: Manual, Signal output cable, Cleaning Brush, Wide angle louver
