Input Voltage: DC24V (with AC adapter for AC100 to 240V)
Indication: Green:Normal condition
Red:Abnormal condition
Buzzer Alarm: When H.V. is abnormal, the buzzer is on.
Abnormal signal output: Contact output under abnormal condition
(MOS FET Realay Normally close , DC30V less 100mA)
Ion Balance: Under ±15V
Ozone density: Under 0.04ppm (Distance at150mm from the nozzle hole)
Air Supply: Clean and Dry air
Air pressure range: 0.05 to 0.6 MPa(with Speed Controller)
Air consumption: Maximum 190 ℓ/min(ANR)
Air blow: CONT : Continuously blow
PULSE Hi : High Speed Pulse(10Hz)
PULSE Lo : Low Speed Pulse(5Hz) *7
Enviroment: 0 to 40℃
15 to 65%RH(without Condensation)
Dimensions: ANZ body : 18 dia ×154L(mm)
Controlbox : 135W×50H×75D(mm)
Weight: ANZ body : 95g
Controlbox : 570g
Accessories: ANZ body, Controlbox, AC adaptor, Grounding cable, Holder(4 pcs), contactpin(5 pcs), air tubing, manual
Option: Emitter needle : DN-W17
Air Pressure Guage
Nozzle Application: Same as ZappⅡ
*7: The life time of electric valve in the controller is below 50 million times.
