SHINING 3D EinScan H2 Handheld 3D Scanner

– Scan Mode: White Light Mode/ IR Mode

– Light Source: White LED Light, Visibl/ Infrared VCSEL Light, Invisible

– Scan Accuracy: Up to 0.05mm/ Up to 0.1mm

– Volumetric Accuracy: 0.05mm±0.1mm/m/ 0.1mm±0.3mm/m

– Point Distance: 0.2mm-3mm

– Best Working Distance: 470mm

– Effective working Distance Range: 200mm-700mm/ 200mm-1500mm

– Maximum FOV: 420mm*440mm/ 780mm*900mm

– Scan Speed: 1,200,000points/s – 1,060,000points/s

– Texture Resolution: 5MP

– Align Modes: Markers Alignment, Feature Alignment, Hybrid Alignment, Texture Alignment / Feature Alignment, Hybrid Alignment, Texture Alignment, Global Markers

– Safety: LED light (eye-safe) – CLASS I (eye-safe)

– Built-in Color Camera: Yes

– Texture Scan: Yes

– Included Software: EXScanH; Solid Edge SHINING 3D Edition

– Output Formats: OBJ, STL, ASC, PLY, P3, 3MF

– Scanner Size: 108 mm*110 mm*237 mm

– Scanner Weight: 731.1 g

– Operating Temperature Range: 0°C ~ 40°C

– Operating Humidity Range: 10% RH ~ 90% RH

– Certifications: CE，FCC，ROHS，WEEE，KC

– Interface: USB 3.0

– Input Voltage: DC：12 V，5.0 A

– Recommended Configuration: OS: Win10/11, 64-bit; Graphics card: NVIDIA GTX/RTX, RTX2060 or better; Video memory: ≥6GB; Processor: Intel I7-11700 or better; Memory: ≥64GB

– Required Configuration: OS: Win10, 64-bit; Graphics card: NVIDIA GTX1060; Video memory: ≥4GB; Processor: Intel I7-8700; Memory: ≥16GB
