Applicable fiber: SMF(ITU-G652), MMF(ITU-G651), NZDS(ITU-G655), DS(ITU-G653),EDF
PM fiber: Panda, Bow-tie and Elliptical fiber
Cladding diameter: 80～125μm
Coating diameter: 160～900µm
Cleaved Length: 9～10µm(standard)
Alignment Method: PAS and fiber end view available
Typical Splice Loss: SMF: 0.03dB, MMF: 0.05dB, NZDS:0.02dB, PMF 0.06dB
Typical Splice Time: SMF/MMF: 15seconds; PM Fiber:＜60seconds
Return Loss: ＞60dB
Splicing program: 40 modes
Heating mode: Manual, Automatic
Operation mode: Manual,Automatic
Extinction Ratio: -36.8dB(PANDA)
Tension test: 1.96N(+0%-+20%)
PM Splicing Function: Support splicing at 0, 45 degree and 90 degree
Electrode Life: ＞2000 times, easy to replace the electrodes
Viewing display: 5 inch color LCD Monitor
Data storage: 8000 groups data records,100 groups images
Operating Condition: -10℃-+50℃
Storage Condition: -20℃-+60℃
Power supply: Adaptor, input: AC100-240V(50/60HZ), output: DC11-13.5V
Terminal: USB 2.0 port, for software upgrading, records exporting, RS232 port, output sigal customizable
Dimension: 330mm(W)×205mm(D)×172mm(H)
Weight: 6.4kg
