ShinewayTech SLS-21-A-00 Entry-level Stabilized Laser Source (1310/1550 nm)

Wavelength (±20nm): 1310/1550

Output Power: ≥0

Display: LCD

Output Mode: CW, 270Hz,1KHz, 2KHz

Emitter Type: FP-LD

Connector Type: FC/PC(Interchangeable SC,ST)

Spectrum Width: ≤ 5nm

Stability: ±0.05dB/15min, ±0.10dB/8hr@ 1310/1550; ±0.15dB/8hr@ 850/1300nm

Fiber Type: Multi/Single Mode Fiber

Auto Off: After 5 minutes idle

Power Supply: 9V Alkaline battery(450mAh) / optional 9V AC adapter

Battery Life: ≥20hours with 9V Alkaline

Operating Temperature: -20°C to 50°C

Storage Temperature: -40°C to 70°C

Relative Humidity: 0 ~ 95% (Non-condensing)

Weight: 300g (0.66lbs)

Dimensions (H×W×T): 145×75×25mm (5.7×2.9×1inch)

 * Specifications subject to change without notice.:

Ordering Information:

Standard Package::

Instrument, 9V Alkaline battery, Rubber Boot, Warranty Card, CE Certificate, Certificate of Calibration, User Manual.:
