Frequency Range : 1–6000 MHz
Frequency Resolution : 1 kHz
Frequency Accuracy : ±2 ppm
Output Power : 0 dBm (typ.)
Measurement Speed : 1.5 ms/pt
Return Loss Range : 0–60 dB
VSWR Range : 1–65
Cable Loss Range : 0–30 dB
Distance-to-Fault Range : up to 1500 m
Phase Measurement Range : −180° to +180°
Spectrum Analyzer Range : 300–4000 MHz
RBW/VBW : 1 k–300 kHz (1, 3, 10 step)
Amplitude Accuracy : ±1.5 dB (typ., 25 ± 5 °C)
Displayed Average Noise Level : ≤ −130 dBm/Hz
Display : 7 inch touch screen (800×480)
Interface : USB Host/Device, LAN Port
Memory : 16 GB (>2000 traces)
Power Supply : 11.1 V / 7800 mAh battery, AC 110–240 V adapter
Operating Temperature : −10 °C to 50 °C
Dimensions (L×W×H) : 290 × 175 × 75 mm
Weight : 2.5 kg
