DC Voltage:
Ranges: 400.0mV / 4.000V / 40.00V / 400.0V / 1000V
Resolution: 100μV / 1mV / 10mV / 100mV / 1V
Accuracy: ±(0.5%rdg+3dgt)
AC Voltage:
Ranges: 400.0mV / 4.000V / 40.00V / 400.0V / 750V
Resolution: 100μV / 1mV / 10mV / 100mV / 1V
Accuracy: ±(1%rdg+5dgt)
DC Current:
Ranges: 400.0μA / 4000μA / 40.00mA / 400.0mA / 10A
Resolution: 0.1μA / 1μA / 0.01mA / 0.1mA / 10mA
Accuracy: ±(1%rdg+5dgt) / ±(2%rdg+2dgt)
AC Current:
Ranges: 400.0μA / 4000μA / 40.00mA / 400.0mA / 10A
Resolution: 0.1μA / 1μA / 0.01mA / 0.1mA / 10mA
Accuracy: ±(1%rdg+5dgt) / ±(2%rdg+3dgt)
Resistance:
Ranges: 400.0Ω / 4.000kΩ / 40.00kΩ / 400.0kΩ / 4.000MΩ / 40.00MΩ
Resolution: 0.1Ω / 1Ω / 10Ω / 100Ω / 1kΩ / 10kΩ
Accuracy: ±(1.5%rdg+3dgt) / ±(2%rdg+4dgt)
Frequence :
Ranges: 4.000kHz / 40.00kHz / 400.0kHz / 4.000MHz / 40.00MHz
Resolution: 1Hz / 10Hz / 100Hz / 1kHz / 10kHz
Accuracy: ±(1%rdg+2dgt)
Continuity:
Ranges: 400Ω
Resolution: 0.1Ω
Continuity beeper: < 35Ω
Low battery indication
Operating temperature: 0ºC ~ 40ºC, 80% Max.
Storage temperature & humidity: -10ºC ~ 50ºC, 80% Max.
Dimensions: 192(L) × 88.5(W) × 45(D)mm
Weight (battery included): Approx. 350g
Power source: 1.5V (AAA) × 2
Safety standard: EN 61010-1 CAT III 600V / EN 61326-1
