Direct access to our certified experts
Low resistance ranges / resolution / Accuracy
0-2.000mΩ / 1μΩ/ ±(5%rdg+5dgt)
0-20.00mΩ / 10μΩ/ ±(4%rdg+4dgt)
0-200.0mΩ / 100μΩ/ ±(4%rdg+4dgt)
0-2.000Ω / 1mΩ/ ±(3%rdg+4dgt)
0-20.00Ω / 10mΩ/ ±(2%rdg+4dgt)
0-200.0Ω / 100mΩ /±(2%rdg+4dgt)
Test current (dc)
2.000mΩ to 200.0mΩ : 1A±3%
200.0mΩ to 20.0Ω : 100mA±2%
200.0Ω : 10mA±1.5%
Maximum output
Voltage (C1~C2) 10V
Dimensions 330(L) × 260(W) × 160(D)mm
Weight (battery included) Approx. 3200g
Power source Rechargeable battery
Safety standard EN 61010-1 ;EN 61326-1
| FEATURES | |||||||||||||||||||||||||||||
| ● Microprocessor-controlled. ● Measure down to 1μΩ. ● 6 ranges from 2.000mΩ to 200.0Ω. ● Maximum resolution of 1μΩ. ● Three test currents with over-temperature protection. ● Four terminal measurement. ● Protection against inadvertent connection to over- voltage. (crow bars for current and voltage) ● Clear & large LCD. ● Potential lead resistance and current lead resistance checks. ● "Full-featured” EnerSave™ Inside. ● EnerSave™ Auto-hold. ● EnerSave™ Auto-off. ● Rechargeable battery operated ● Robust & compact. ● Indicators show if reading may be invalid (RP, RC, and temperature). ● "O-Ring” sealed case. |
|||||||||||||||||||||||||||||
| SPECIFICATIONS | |||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||
