Flow Ranges: Low: 5-450 cc/min, Standard: 50-5000 cc/min, High: 1-30 LPM
Volumetric Accuracy: ±1% of reading
Temp. & Pressure Sensor: YES, in flow stream
Time per Measurement: 1-15 seconds
Sampling Mode: Instantaneous, Averaging
Averaging Function: Selectable; 3 to 20 Measurements
Gas Compatibility: Non-corrosive, non-condensing
Flow Modes: Pressure or Suction
AC Adapter / Charger: 12 VDC
Battery System: Lithium (LiFePO4) (see Certifications below)
Battery Run Time: 3 hours max flow, 8 hours continuous use (min brightness)
Battery Charge Time:
12 VDC Adapter: 3 hr
USB: 7 hrs (unit off)
Operating Temperature: 10-40°C (50-104°F)
Storage Temperature: 0-70°C (32-158°F)
Operating Humidity: 0-85% RH, non-condensing
Storage Humidity: 0-100% RH, non-condensing
Display: Color Graphic LCD, HMI Touch Screen
Data Port: RS-232 (for Pump interface), USB (for data)
Transportable Storage: SD Card
Protective Hard Shell Case: Carrying case for 1 to 3 Cells
Dimensions (HxWxD): 6.6” x 9.2” x 3.2” (168 x 234 x 81 mm)
Weight:
Base: 2.8 lbs / 1,270 g
Low Flow Cell: 0.8 lbs / 363 g
Std Flow Cell: 0.85 lbs / 385 g
High Flow Cell: 1 lb / 454 g
