Sensor element : NiCr-Ni (type K)
Measuring range : -200..+1150 °C
Probe diameter D : 0.5 mm, 1 mm, 1.5 mm, 3 mm, 6 mm (other diameters upon request)
Fitting length EL : 150 mm, 250 mm, 500 mm, 1000 mm, 1500 mm, other fitting lengths possible
Cable sleeve : for probe diameter D 0.5 mm, 1 mm, 1.5 mm, 3 mm:
cable sleeve Ø 5 mm x 50 mm additional to fitting length
for probe diameter D 6 mm: cable sleeve Ø 8 mm x 35 mm and diminution Ø 5 mm x 17 mm additional to fitting length
Note: : The temperature of the cable sleeve must not exceed the permitted temperature of the cable
Accuracy : class 1
Tube material : cable sleeve: V4A
probe tube: Inconel 600
Cable : 1 m silicone compensation line (std), loose ends
PVC cable : up to max. 105 °C
Silicone cable : up to max. 200 °C (standard)
Teflon cable : up to max. 250 °C
Glass silk cable : up to max. 400 °C
