Set-Option: Device in case GKK 1002, test protocol, batteries, manual
Accuracy
Barometer:
Typ.: ± 1 hPa (at T: 0 .. 30 °C)
max.: ± 0.25 % FSS equals ± 2 hPa
Altimeter: Typ. ± 1 m rel. (over a short time with const. ambient pressure @ 25°C)
Temperature:
Typ. ± 0.5 °C @ 25°C
Additional functions:
NULL: Tare-function, respectively comfortable altitude setting
AVR: Averaging over 2 s / 5 s / 10 s
Only as Altimeter: Variometer display can be shown with ft/h, m/s, m/h
Adjustment: Zero point and slope
Auto power off: If activated, instrument powers down automatically
Connections:
No connection, integrated sensor
Pressure compensation via membrane
Dimensions: 108 x 54 x 28 mm
Display: 3-line segment LCD, additional symbols, backlight
Housing material: Break-proof ABS housing
Measurement rate:
FAST: 10 measurements per second
SLO: Ca. 1 measurement per second
Operating conditions: -20 ... 50 °C; 0 ... 95 % r.F. (short-term dewing possible)
Overload: 4000 hPa abs.
Power supply: 2 x AA batteries (in scope of supply)
Protection type: IP67
Standard functions:
Min/Max/Hold, Auto-Power-Off-Function
Tendency display, time base selectable (1s, 60s, 1h, 3h)
Only as Altimeter: The covered altitude meters are calculated (ascent ASC, descent DESC, resolution 1m)
Weight: 140 g incl. battery
Measuring range
Barometer:
300.0 .. 1100.0 hPa (mbar) abs.
4.350 .. 15.950 PSI abs.
225.0 .. 825.0 mmHg (Torr) abs.
Altimeter:
-500.0 .. 9000.0 m
-1640 .. 19999 ft
Temperature:
-20.0 .. 50.0 °C
-4.0 .. 122.0 °F
Current supply: 2 x AA batteries
Pressure connection: without
Working temperature -20 ... +50 °C
