Set-Option: Device in carton box, testprotocol, batteries, manual
Accuracy:
– 20 ... +100 °C: ±0.1 K ±1 digit
– 70 ... +250 °C: ±0.2% of measured value ±2 digits
Connections: Fixed Pt1000 sensor
Dimensions: 108 x 54 x 28 mm (H x W x T) without sensor
Housing material: Break-proof ABS housing
Operating conditions: – 20 ... +50 °C; 0 ... 95% relative humidity (non-condensing), temporarily usable up to 100% relative humidity
Power consumption: approx. 5000 h operating time
Power supply: 2 x AA battery
Protection type: IP65/IP67
Weight: 130 g (without sensor)
Display: 3-line with battery status indicator, Backlight, protected by shatterproof screen, overhead display at the push of a button
Measuring range: – 70.0 ... +250.0 °C (– 94.0 ... +482.0 °F)
Cable: Cable length 1 m silicone cable
Current supply: 2 x AA batteries
Measuring input: Pt1000 (2-wire)
Probe (permanently connected): With robust insertion probe, Ø3 mm, handle and cable shorttime 250°C, permanent 230°C
Resolution: 0.1 °C
Sensor connection: Probe fixed on the device
Working temperature: -20 ... +50 °C
