Applications: Immersion, insertion
Dimensions: Stem: Ø3 mm, L=150/300 mm (other lengths on request)
Cable: Ø4 mm, L=1,.2 or 5 m
Materials: Stem: AISI 316
Handle: Polyamide (PA6-GF30)
Cable: PVC (permanently up to +80 °C / short-term approx. 2 hours per application up to +105 °C)
Measuring range: -50 ... +250 °C
Output: Pt100 4-wire
Protection degree: IP67
Response time : water 0.4 m/s < 2 s, air 2 m/s approx. 40 s
Sensor: Pt100 (wire wound)
Weight: 110 g approx. with 2 m cable
Accuracy: Class AA, (valid range 0...+150°C)
Connection: M12 4-pole male A-coded or loose ends
Cable and length: 1 m PVC cable, -20 ... +105 °C
Diameter probe tube: Ø3 mm
Probe length: 150 mm
