Sensata Technologies - Crydom D2425D Controller 25A 280VAC DUAL
Manufacturer: Sensata Technologies - Crydom Model: D2425D - Contact
Width: 45.3 mm
Height: 33.2 mm
Length: 58.4 mm
IP Rating: IP00
Output Type: SCR
Unit Weight: 75 g
Contact Form: SPST (1 Form A)
REACH - SVHC: Details
Input Current: 13 mA
Mounting Style: Panel Mount
Termination Style: Screw
Relay Contact Form: 2 Form A (DPST-NO)
Load Current Rating: 25 A
Load Voltage Rating: 24 VAC to 280 VAC
Control Voltage Range: 4 VDC to 15 VDC
Pd - Power Dissipation: 500 mW
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 40 C
