Sensata Technologies - Crydom CN048D24 Miniature 48VDC/0.1A, 24VDC input, 6mm SIP SSR

Width: 5 mm (0.197 in)

Height: 15 mm (0.591 in)

Length: 28 mm (1.102 in)

Output Type: MOSFET

Unit Weight: 4.050 g

Contact Form: SPST (1 Form A)

REACH - SVHC: Details

Input Current: 5 mA

Mounting Style: PCB Mount

Termination Style: Solder Pin

Relay Contact Form: 1 Form A (SPST-NO)

Load Current Rating: 100 mA

Load Voltage Rating: 48 VDC

Control Voltage Range: 3 VDC to 12 VDC

Maximum Operating Temperature: + 80 C

Minimum Operating Temperature: - 20 C
