Sensata Technologies - Crydom 7PCV2425 Heavy Duty Prop.Contr.SSR 240 VAC/25A 2-7VDC

Width: 45.7 mm

Height: 23 mm

Length: 58.4 mm

Output Type: SCR

Unit Weight: 100 g

Contact Form: SPST (1 Form A)

REACH - SVHC: Details

Input Current: 4 mA

Mounting Style: Panel Mount

Termination Style: Screw

Relay Contact Form: 1 Form A (SPST-NO)

Load Current Rating: 25 A

Load Voltage Rating: 100 VAC to 240 VAC

Control Voltage Range: 2 VDC to 7 VDC

Maximum Operating Temperature: + 80 C

Minimum Operating Temperature: - 30 C
