Gas type: LNG, 0~100%LEL
Dimension: 194 (H) X 152.4 (W) X 136 (D) mm
Weight: 4kg
Operating Voltage DC : 24V ±10%, PoE : 36V~57V (Typical : 48V)
Flow Rate: 100~1,000ml (Normal 300~500ml/min)
Power Consumption: Approximately 5.0W
Measuring Type Display: FND, Gas concentration, Flow rate, Alarm, Device faulty
Relay: Low Alarm, High Alarm, Fault Alarm
Output Signal: 4-20mA
Digital Communication: RS-485, TCP Ethernet
Sampling Distance: Length of input gas tube : Up to 30m (FEP tube),Length of exhaust gas tube : Up to 30m (FEP tube)
Input/Output Tube: 1/4” Teflon tube
Operating Temperature: -40°C ~ +55°C
Control/Set: 4 Buttons & RS-485 & Ethernet & Bluetooth
Remote Interface: Ethernet, RS-485
Wiring: 4 to 20mA / DC power / Relay : Up to 14 AWG
Pressure range: 90 to 100kPa
Maximum Sample: flow Max 1,000ml
Maximum Sample: Pressure 6kPa
Certification: IECEx Ex db llC T6 Gb, TEX II 2 G Ex db IIC T6 Gb
Standard Package
- Detector
- Filter
- Plug
- Manual
- Magnetic Bar
- Calibration Cap
- Certificate
