Gas: Oxygen
Sensor: Electrochemical
Range: 0~30%Vol
A1: 19.0%vol
A2: 23.0%vol
Resolution: 0.1%vol
Measuring Type: Diffusion Type
Dimension: 169(W) x 188.5(D) x 107(H)mm
Weight: 2.4kg
Measuring Value Display: FND, Gas Concentration, Alarm, Device Faulty
Relay: Low Alarm, High Alarm, Fault Alarm (Rated 2.0A @30Vdc)
Analog Output Signal: 4-20mA
Digital Communication: RS-485
Operating Temperature: -40°C ~ +60°C
Control/Set: 4 Button & RS485 & Bluetooth
Remote Interface: RS-485 Modbus, HART(Option)
Wiring: 4 to 20mA / DC Power / Relay : up to 14 AWG
Explosion proof: Explosion-proof enclosure
Body Material: Aluminum
Input Voltage: DC : +24Vdc ±10%
Analog Output current
Fault : 0mA, 0~100% : 4~20mA(all readings : ± 0.2mA)
Maintenance/Initialize: 3mA
