SENKO SI-100IS Detector for Detecting Oxygen, Toxic Gas and Combustible Gas

Measuring range: Programmable within dectection range
Display: 30-Bar graph, 3 Alarm LED, 3 Status LED, 7-Segment(4Digit)
Sound: buzzer(Alarm1,2,3, Reset, Fault), 80dB
Operation mode display: 3 Alarm LED, 3 Status LED
Measuring value display: 30-Bar graph, 7-Segment(4Digit)
Alarm level set: Alarm1,2,3 Programmable within dectection range
Alarm signal output: Alarm 1,2,3 - 12V.DC, Dry contact (com, no, nc), comm 12V.DC, Dry contact(com, no, nc)
Input Signal: 4/20mA signal
Output signal: 4/20mA signal, RS-485(Option)
Reset signal: Reset switch, RS-485(Option)
Cable/Distance: CVVSB1.5SQ x 3Wire (Power + signal) / 2,500m max
Mounting type: Wall mount
Program set mode: ALARM1,2,3, Range, 4-20mA Calibration etc.
Operating power: 110V~240V INPUT AC (50/60Hz), < 0.24A
Material: ABS AF308
Dimensions: 120(W) x 200(H) x 51(D)
Weight: 0.5kg
