Specifications
Maximum measurement range / Resolution / frequency range:
Parameter Maximum
Measurement Range Maximum
Resolution Frequency Range
Displacement Peak-Peak value 2 mm : 1 micron; 10 – 500Hz
Velocity RMS value 200mm/s: 0.1 mm/s 10 – 1000Hz
Acceleration Peak value 180m/s2: 0.1 m/s2; 10 – 5000Hz
High Frequency Acceleration Envelope 20unit: 0.1unit 5Hz-2kHz #
Note: Demodulated from 15kHz-40kHz
Accuracy of vibration measurement:
Noise Level (without vibration input): ACC<0.25 m/s2, VEL<0.5mm/s, Disp<1um
Frequency response accuracy: ±5% + 2 digits
Non-linearity: ±5% + 2 digits
Rechargeable battery, Automatic power off, >20 hours operation time
Operation temperature range: 0 - 50°C
Pickup: Accelerometer with extension stinger and magnetic mount, Optional tacho-sensor
Rotation speed measurement range: 10-60000 RPM
Storage: optional 60 or 200 sets of ID, acceleration, velocity, displacement, envelope & spectrum
Size: 196 x 101 x 45 (mm)
Weight: 230 gram (including battery)
