Power supply: 230V~ 50/60 Hz
Power absorption: 6VA
Sensor type: Semiconductor SnO2, replaceable
Detected gas: Methane
Calibration threshold: 10% L.I.E.
Contact ratings: 6(2)A250V~ SPDT
Frequency: 868.150 MHz
Modulation: GFSK
Max. RF power transmitted: 1 mW
Bandwidth (-3 dB): 100 KHz
Antenna type: Internal stylus
Max. distance from the receiver:
>300 m in free air
>50 m in building (depending on the building and environment)
Indicators:
Operation: Green led
Alarm: Red led
Fail: Yellow led
Alarm: Buzzer
Activation delay: ~ 30 seconds
Relay activation delay: ~ 5 seconds
Sensor lifetime: 5 years
Operating temperature: 0°C .. 40°C
Storage temperature: -10°C .. +50°C
Humidity limits: 20% .. 80% RH (non condensing)
Protection grade: IP 42
Case: Material: ABS V0 self-extinguishing
Color:
Cover: Signal white (RAL 9003)
Details: Mouse grey (RAL 7005)
Size: 148 x 84 x 40 mm (WxHxD)
Weight: ~ 300 gr.
