Display: 7 inch touch screen
Processing range: 0.75 - 30mm²
Max. diameter of the conduit: Φ18mm
Cable type: Single-core wire, multi-core wire, power cord, multi-layer wire, shielded wire, electric wire, etc.
Stripping length: Front full stripping: 1-200mm; Front half stripping: 1-1500mm; End full stripping: 1-100mm; End half stripping: 1-300mm
Dimensions (LWH): 1280x480x1350mm
Net weight: 180kg
Cutting length: 120mm-999999.99mm
Cutting tolerance: ≤0.002*L (L = cutting length)
Blade material: High-quality high-speed steel
Rotary cutter material: White steel / tungsten steel (optional)
Productivity: 800-100PCS/hour (depending on the length and size of the cable)
Drive mode: 16 rollers drive (feeding-stepper motor, blades-servo motor, rotary cutter-servo motor)
Wire feeding method: Belt feeding, no embossing or scratches on the cable
Lift operation mode: Digitally adjust the height of the pressure roller
Power supply: AC220V 50/60Hz; 110V 50/60Hz
Air source: 0.5Mpa
