Range: 30kΩ, 3kΩ, 300Ω, 30Ω, 3Ω, 200mΩ
Resolution: 1Ω, 100mΩ, 10mΩ, 1mΩ, 100µΩ, 10µΩ
Minimum Current: 10µA, 100µA, 1mA, 10mA
Maximum Current: 100µA, 1mA, 10mA, 100mA
Accuracy at Full Rated Current: ± (0.03% Rdg + 0.02% FS), ± (0.03% Rdg + 0.01% FS)
General specification:
Measurement: 4 Terminal Kelvin/Thomson principle eliminates errors due to lead resistance.
Display: LCD graphics panel with backlit 30,000 count.
Ranges: 8 automatic or manual selection.
Terminals: 4mm safety sockets.
Working Temperature: 0°C to +45°C rel, humidity 80% max, non-condensing.
Storage Temperature: -20°C to +60°C
Mains Supply: 115/230V, +/-10%, 47Hz to 63Hz, 250VA
Safety: EN 61010-1 EMC-EN 61236
Dimensions: 33.9cm x 32.4cm x 13.1cm (w x h x d) approx.
Shipping Information: DO5000 46 x 47 x 31 11kg
Auto Zero: Permits the zero of measurement values.
Average: Automatic average and display of measurement with forward and reverse current.
Auto Temperature Compensation: Automatically references measurement to temperature of 20°C or user defined temperature.
User coefficients may be used. External Pt100 senses temperature or manual value can be used.
High/Low limits: Limit values can be set over the entire measurement range.
Supplied with RS232 interface, mains cord, handbook and certificate of conformity
