Internal Size(W×D×H): 610×550×600mm
External Size(W×D×H): 710x780x1430mm (Without base stand)
710x780x2050mm (With base stand)
Work Surface Height: 750mm
Airflow System: 70% air recirculation, 30% air exhaust
Downflow Velocity: 0.35m/s (Airflow fluctuation over 20%, there is visual and audio alarm)
Inflow Velocity: 0.52 m/s (Airflow velocity less than 0.40 m/s, there is Visual and Audio alarm)
Filter Specification: H14 HEPA filter, ≥99.995% efficiency at 0.3μm
Supply HEPA Filter Size: 570×490×70mm
Exhaust HEPA Filter Size: 540×370×70mm
Cleanliness Grade: Class 100 (ISO14644.1 Class 5)
Display
1. LCD touch screen.
2. Real-time monitoring and display front window status.
3. Inflow and downflow velocity.
4. Pressure.
5. Date/time/temperature.
6. Filter and UV lamp life.
7. System working status etc.
Alarm
1. Abnormal airflow velocit
2. HEPA filter failure
3. UV lamp failure
4. Front window at unsafe height
Front Window: Motorized, toughened glass
LED Lamp: 10w×2
UV Lamp: 15w×1
Rated Consumption /Max.Consumption: 260w/320w
Not include socket consumption
Explosion-proof Socket 3A 1pcs (IP54)
Socket Power Consumption Support: <1100w (220V), <550W (110V)
Illumination: ≥900Lx
Sound Emission: ≤60dB(A)
Work Surface Net Vibration Amplitude: ≤2μm
Power Supply: AC220V/50Hz; 110V/60Hz
Material: External Main Body: Electro-galvanized steel with antimicrobial powder coating
Work Surface: 304 stainless steel
Standard Accessories:
1. Air velocity sensor
2. LCD touch screen
3. LED lamp
4. UV lamp
5. Explosion-proof/Waterprof socket
6. Motorized front window
7. Footmaster caster
8. Foot switch
9. Removable shallow-plate stainless steel work surface
Net Weight 220kg
Gross Weight 270kg
Shipping Size (W×D×H) 850×990×1650mm
Shipping Volume 1.4 m3
