Nominal Frequency Range:400 MHz...3 GHz
Usable Frequency Range:340 MHz ... 4 GHz
Isotropic Gain: typ.7 dBi +/- 1 dB
Antenna Facto : 15 ... 34 dB/m
Nominal Impedance: 50 Ω
Standing Wave Ratio SWR max.: < 2.8 (f < 2.3 GHz)
Standing Wave Ratio SWR typical: < 1.5 (f < 2.3 GHz)
Front to Back Ratio: typ. 20 dB
Cross Polarisation: >20 dB (340 MHz...1.3 GHz)
3 dB Beamwidth typ. (E-Plane): 40°-65°
3 dB Beamwidth typ. (H-Plane): 80°-120°
Max. Input Power: 300 W (1 GHz)
N-Connector female
Mount: 22 mm Tube, Indexing Ring
Width × Length × Thickness: 450 x 635 x 72 mm
Weight: 1.3 kg
