Input Impedance: 1.5 kΩ || 4 pF
Frequency Range: 9 kHz – 30 MHz
Voltage range:
HF: < 30 V
AC 50 / 60 Hz: < 2.5 kV
DC: < 4.4 kV
Freq. Range w. constant Correction of 30 dB: 20 kHz – 30 MHz
Accuracy of Voltage Division: 30 kHz – 30 MHz ±1.0 dB
Input Impedance of Test Receiver: 50 Ω, SWR ≤ 1.1
Internal Coupling Capacitor: 10 nF
Terminals: 4 mm jack
Ground Connection: insulated litz wire, Banana plug
Coax cable: RG 58, 2 m, BNC
Audio Frequency Impedance: 10 nF + 1.5 kΩ
Weight: 180 g
Dimensions: 175 mm × 23 mm Ø
