Nominal Insertion Loss in 50 Ω System: 34 dB
Transfer Impedance: 1 Ω
Nominal Frequency Range: 150 kHz – 30 MHz
Usable Frequency Range: 9 kHz – 80 MHz
Conversion (Current → Voltage): 1 µA = 1 µV
VSWR: typically < 1.2
Usable Frequency Range with AC 5 A (50 Hz, –1 dB): 290 kHz – 80 MHz
Usable Frequency Range with AC 10 A (50 Hz, –1 dB): 330 kHz – 80 MHz
Usable Frequency Range with AC 20 A (50 Hz, –1 dB): 520 kHz – 80 MHz
Connector: BNC female
Dimensions: 188 × 53 × 28 mm
Maximum Wire Diameter: 23 mm
Material: Aluminium
Weight: 260 g
