Frequency Range: 0.15 MHz – 30 MHz
Max. continuous current: 100 A
Max. current (limited time, 4 min): 150 A
Max Voltage (DC): 1500 V
Common Mode Impedance (Mode switch CM, A, or B): (150 ± 30) Ω
Differential Mode Impedance (Mode switch DM): (150 ± 30) Ω
Phase at EuT-Terminals: (0 ± 40)°
Insertion loss (EuT – AE): > 20 dB
Longitudinal conversion loss: > 20 dB
Voltage Division Factor at the measuring port: Typ. (20 ± 3) dB (10:1)
Resistance (DC) with feed terminals shorted: 90 mΩ
EuT Connectors: Wing terminals
Dimensions (W × H × D): 448 × 191 × 470 mm
Weight: 15 kg
