Frequency Range: DC – 5 (10) MHz
Impedance:
|Z| = 480 Ω f < 1 MHz
|Z| = 500 Ω f = 3 MHz
|Z| = 550 Ω f = 5 MHz
Number of Turns: 10
Loop Diameter: 50 mm
Maximum Current: 100 mA / 100 dBµA
Maximum Voltage: 50 V / 154 dBµV
Inductance: 7 µH
Capacitance: ≈ 23 pF
Resistance: 480 Ω
Self-Resonance Frequency: 13 MHz
Mechanical Dimensions: 60 × 104 × 62 mm
Terminals: BNC
Mount: 3/8"
Weight: 165 g
