Frequency Range (nominal): 1-2 GHz
Frequency Range (useable): 30.9-2.2 GHz
Gain: ≈ 19-22 dBi
Antenna Factor: 12...15 dB/m
VSWR: typ. < 1.5
Front to Back Ratio: typ. > 27 dB
Half Power Beamwidth (E-Plane): 17° @ 1 GHz/ 13° @ 1.5 GHz/ 11° @ 2 GHz
Half Power Beamwidth (H-Plane): 19° @ 1 GHz/ 14° @ 1.5 GHz/ 16° @ 2 GHz
Connector: 7/16
Max. Input Power: 2 kW (2 GHz)
Max. Peak Input Power: 10 kW
Mounting Threads: 3/8" , M12
Dimensions: 0.72 x 0.96 x 1.84 m
Weight: 18 kg
Material: Aluminium
